Page #135 background imageLoading...
Page #135 background image
NOTE: You can also determine the BIOS version by turning on or restarting the computer, pressing
the esc key while the “Press the ESC key for Startup Menu” message is displayed at the bottom of the
screen, and then pressing the f1 key. Follow the on-screen instructions to exit this screen.
Downloading a BIOS update
CAUTION: To reduce the risk of damage to the computer or an unsuccessful installation, download
and install a BIOS update only when the computer is connected to reliable external power using the AC
adapter. Do not download or install a BIOS update while the computer is running on battery power,
docked in an optional docking device, or connected to an optional power source. During the
download and installation, follow these instructions:
Do not disconnect power from the computer by unplugging the power cord from the AC outlet.
Do not shut down the computer or initiate Suspend or Hibernation.
Do not insert, remove, connect, or disconnect any device, cable, or cord.
1. Open your web browser. For U.S. support, go to http://www.hp.com/go/contactHP. For
worldwide support, go to
http://welcome.hp.com/country/us/en/wwcontact_us.html.
2. Follow the on-screen instructions to identify your computer and access the BIOS update you want
to download.
3. Click the option for software and driver downloads, type your computer model number in the
product box, and then press enter. Follow the on-screen instructions to identify your computer and
access the BIOS update you want to download.
4. Click your specific product from the models listed.
5. Click the appropriate operating system.
6. Go to the BIOS section and download the BIOS software package.
7. Follow the installation instructions as provided with the downloaded BIOS software package.
NOTE: After a message on the screen reports a successful installation, you can delete the
downloaded file from your hard drive.
HP Sure Start
Select Intel-based 2013 HP Business Notebook PCs offer HP Sure Start, which provides hardware-
based assurance of the following:
HP-approved firmware is running on the HP Embedded Controller (EC) – EC Options in BIOS
found under “BIOS Integrity Checking”
An HP-approved BIOS is running on the host processor
HP Sure Start verifies the integrity of critical, non-executable platform data residing in the main flash
and provides selfhealing mechanisms to restore any code or critical platform data that has been lost or
is corrupted within the flash.
HP Sure Start
123

Table of Contents

Other manuals for HP EliteBook 850 G1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 850 G1 and is the answer not in the manual?

HP EliteBook 850 G1 Specifications

General IconGeneral
Form factorClamshell
Product typeLaptop
Product colorBlack, Silver
Country of originChina
Intel® vPro™ Platform EligibilityNo
Bus typeDMI2
SteppingC0
Tjunction100 °C
Processor cache3 MB
Processor cores2
System bus rate- GT/s
Processor familyIntel® Core™ i5
Processor seriesIntel Core i5-4200 Mobile series
Processor socketBGA 1168
Processor threads4
Processor codenameHaswell
Processor frequency1.6 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor boost frequency2.6 GHz
Processor operating modes64-bit
PCI Express configurations1x4, 2x4
Thermal Design Power (TDP)15 W
Maximum number of PCI Express lanes12
Motherboard chipset-
Memory slots2x SO-DIMM
Internal memory8 GB
Memory clock speed1600 MHz
Internal memory typeDDR3L-SDRAM
Maximum internal memory16 GB
Memory layout (slots x size)1 x 8 GB
SSD capacityThe Solid State Drive's storage capacity in Gigabytes.
SSD interfaceSATA
Storage mediaSSD
Card reader integratedYes
Total storage capacity256 GB
Number of SSDs installed1
Display diagonal15.6 \
Native aspect ratio16:9
On-board graphics card ID0xA16
On-board graphics card modelIntel® HD Graphics 4400
On-board graphics card familyIntel® HD Graphics
Maximum on-board graphics card memory1.74 GB
On-board graphics card base frequency200 MHz
On-board graphics card dynamic frequency (max)1000 MHz
Intel segment taggingEnterprise
Audio systemDTS Studio Sound
4G standardLTE
3G standardsHSPA
Wi-Fi standards802.11a, 802.11b, 802.11g
Bluetooth version4.0
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile network generation4G
Charging port typeDC-in jack
USB 2.0 ports quantity0
Pointing deviceTouchpad + Pointing Stick
Bundled softwareHP 3D DriveGuard\\r HP Connection Manager (Windows 7)\\r HP Wireless HotSpot\\r HP Mobile Connect (EMEA)\\r HP PageLift\\r HP Recovery Manager\\r HP Support Assistant\\r HP ePrint\\r HP 3D DriveGuard
Operating system installedWindows 7 Professional
Optional operating system suppliedWindows 8.1 Pro
Processor codeSR170
Processor ARK ID75459
Intel TSX-NI version0.00
Processor package size40 x 24 x 1.5 mm
Intel ME Firmware Version9.5
Supported instruction setsAVX 2.0
Intel Smart Connect Technology version1.00
Battery capacity50 Wh
Battery life (max)- h
Number of battery cells3
AC adapter power45 W
Weight and Dimensions IconWeight and Dimensions
Depth253.6 mm
Width375.5 mm
Weight1880 g
Height (front)21.4 mm
