No or bad external video via docking
Symptoms
No or bad image on external monitor
via ports of docking station (VGA, DP,
TB, display port, etc.)
Possible causes
Rooted from system board, software/drivers, dock connectors, docking station hardware/
rmware, dock video ports (DP, VGA, etc).
Troubleshooting steps
1. Be sure that external monitor is powered on.
2. Be sure that external monitor is compatible with the computer.
3. If applicable, plug the dock in dierent Type-C ports.
For more information, see the technical white paper titled ”HP ZBook 65/150/200 W
Thunderbolt 3 Dock User Guide.” Go to http://support.hp.com/, enter your model
number, and then click Manuals > Technical white papers.
4. If the screen image is distorted, try a DP-to-VGA adapter. Connect the adapter to each
DisplayPort and VGA port of the dock.
5. Test the monitor via internal ports (VGA, DP, HDMI, etc.).
6. Verify that dock connectors of the notebook and the dock are clean, without dust,
debris (e.g., using air duster).
7. Ideally, use a veried working operating system/system connected to the dock to
isolate the issue of the current operating system.
8. Ideally, use a veried working docking station to isolate the faulty dock.
9. Update latest dock rmware. Be sure to follow the installation instructions carefully.
You may want to try a DP-to-VGA adapter if you have a distorted screen image. Connect
the adapter to each DisplayPort of the dock. If you still cannot update the dock,
attempt to update it on a conrmed working notebook before having the dock
replaced.
Note See the technical white paper titled “Multiple displays on HP ZBook Mobile Workstations”
from HP platform support website. Go to http://support.hp.com/, enter your model number,
and then click Manuals > Technical white papers.
Incorrect or missing color/distorted image
Symptoms
System works normally but the display
shows:
●
Missing or strange color
●
Image distortion
Possible causes
Loose connection, display cable, display, graphics card.
Troubleshooting steps
Verify with external monitor (i.e., VGA)
1. Use combination Fn + F4 to enable output to external monitor.
2. Close the lid.
If the external monitor also shows incorrect color, it is graphics card issue. Test with a
veried working graphics card.
Verify display cable and cable connection–Display disassembly is required.
Be sure that external display cables are not pinched or damaged.
Common issues and possible solutions 123

HP EliteBook 850 G3 Specifications

General

Form factor	Clamshell
Product type	Ultrabook
Product color	Silver
Country of origin	China
Bus type	OPI
Stepping	D1
Tjunction	100 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-6500U
System bus rate	4 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-6500 Mobile series
Processor socket	LGA 1356 (Socket B2)
Processor threads	4
Processor codename	Skylake
Configurable TDP-up	25 W
Processor frequency	2.5 GHz
Processor cache type	Smart Cache
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.1 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x4, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.6 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Numeric keypad	Yes
Pointing device	Touchpad
Recovery operating system	Windows 10 Pro
Operating system installed	Windows 7 Professional
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	1 x 4 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA
Storage media	SSD
Total storage capacity	512 GB
Compatible memory cards	SD, SDHC, SDXC
Number of SSDs installed	1
Display diagonal	15.6 \
Native aspect ratio	16:9
On-board graphics card ID	1916
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 520
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1050 MHz
Battery capacity	46 Wh
Number of battery cells	3
AC adapter power	65 W
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Sustainability certificates	ENERGY STAR
Processor code	SR2EZ
Processor ARK ID	88194
Processor package size	42 X 24 mm
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Intel Smart Response Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Intel segment tagging	Enterprise
HP segment	Business
HP Software provided	HP BIOSphere with HP Sure Start, HP Client Security, HP Image Assistant, HP SoftPaq Download Manager, HP Connection Manager, HP Noise Reduction Software, HP Clear Sound Amp

Weight and Dimensions

Depth	257.7 mm
Width	383.3 mm
Height	19.4 mm
Weight	1880 g
