Item Component Spare part number
Intel i5-8250U processor L15516-001
Intel i5-7300U processor L15523-001
Intel i5-7200U processor L15514-001
(16) Fan L22307-001
Heat sink
(17) For use in models with discrete graphics memory L14363-001
(18) For use in models with UMA graphics memory L14362-001
(19) Memory module (DDR-2400)
4-GB 862397-850
8-GB 862398-850
16-GB 865396-850
(20) WLAN/Bluetooth combo card
Realtek RTL8822BE 802.11ac 2x2 Wi-Fi + Bluetooth 4.2 Combo Adapter 915623-001
Intel Dual band wireless-AC 8265 802.11AC 2x2 WiFi + Bluetooth 4.2 Combo Adaptor
(vPro)
851592-001
Intel Dual band wireless-AC 8265 802.11AC 2x2 WiFi + Bluetooth 4.2 Combo Adaptor (non-
vPro)
851594-001
(21) WWAN module
LTE CAT4: Huawei HP lt4132, LTE/HSPA+ w/GPS M.2 845710-003
LTE CAT9: Fibocom Intel XMM 7360 LTE-Advanced 917823-001
(22) Solid-state drive (SSD)
1 TB, PCIe, Gen3×4, NVMe, TLC L17246-001
512 GB, PCIe, Gen3×4, SS, NVMe, TLC L17251-001
512 GB, PCIe, Gen3×4, Self-encrypting drive (SED), Opal 2, TLC L17250-001
512 GB, SATA-3, FIPS-140–2, TLC L17249-001
360 GB, PCIe Gen3×4, NVMe,TLC L17252-001
256 GB, PCIe, Gen3x4, SS, NVMe, TLC L17247-001
256 GB, PCIe, NVMe, value L17248-001
256 GB, SATA-3, Opal 2, TLC L17254-001
128 GB, SATA-3, TLC L17245-001
(23) Battery (3 cell, 56 WHr, 4.85 Ah) 933322-855
(24) Bottom cover (includes sponges) L14360-001
26 Chapter 3 Illustrated parts catalog
