19. If it is necessary to replace the WLAN antenna cables, peel the antennas from the top of the display
enclosure (1), remove the antenna cables from the routing path on the bottom of the display enclosure
(2), and then remove the antenna cables (3).
NOTE: The WLAN antennas are spared with the display enclosure.
20. If it is necessary to replace the WWAN antenna cables, peel the antennas from the top of the display
enclosure (1), remove the antenna cables from the bottom and sides of the display enclosure (2), and
then remove the antenna cables (3).
NOTE: The WWAN antennas are spared with the display enclosure.
The display enclosure is available using spare part number L15525-001 for models without a WWAN
module and L15524-001 for models with a WWAN module.
Reverse this procedure to reassemble and install the display assembly.
Component replacement procedures 81
