Page #55 background imageLoading...
Page #55 background image
Creating recovery media with HP Recovery Disc Creator
HP Recovery Disc Creator is a software program that offers an alternative way to create recovery
media. After you successfully set up the computer, you can create recovery media using HP
Recovery Disc Creator. This recovery media performs a system recovery if the hard drive becomes
corrupted. A system recovery reinstalls the original operating system and the software programs
installed at the factory, and then configures the settings for the programs.
HP Recovery Disc Creator can create two kinds of recovery DVDs as follows:
Windows DVD—Installs the operating system without additional drivers or applications.
Choosing this selection creates a DVD that restores the original operating system and the
software programs installed at the factory.
Driver DVD—Installs specific drivers and applications only, in the same way that the HP
Software Setup utility installs drivers and applications.
Creating recovery media
NOTE: Operating system recovery media can be created only once. Thereafter, the option to create
that media will not be available.
1. Select Start > All Programs > Security and Protection > HP Recovery Disc Creator.
2. Select Driver DVD or Windows DVD.
3. From the drop-down menu, select the drive for burning the recovery media.
4. Click the Burn button to start the burning process.
Backing up your information
Recovery after a system failure is as good as your most recent backup. Immediately after software
setup, you should create system repair discs (select models only) using HP Recovery Disc Creator
using the installed optical drive (select models only) or an optional external optical drive and back up
your system. As you add new software and data files, you should continue to back up your system on
a regular basis to maintain a reasonably current backup. The system repair discs (select models only)
are used to start up (boot) the computer and repair the operating system in case of system instability
or failure. Your initial and subsequent backups allow you to restore your data and settings if a failure
occurs.
You can back up your information to an optional external hard drive, a network drive, or discs.
Note the following when backing up:
Store personal files in the Documents library, and back it up regularly.
Back up templates that are stored in their associated programs.
Save customized settings that appear in a window, toolbar, or menu bar by taking a screen shot
of your settings. The screen shot can be a time-saver if you have to reset your preferences.
When backing up to discs, use any of the following types of discs (purchased separately): CD-R,
CD-RW, DVD+R, DVD+R DL, DVD-R, DVD-R DL, or DVD±RW. The discs you use will depend
on the type of optical drive you are using.
Creating recovery media with HP Recovery Disc Creator 47

Table of Contents

Other manuals for HP EliteBook 8570p

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 8570p and is the answer not in the manual?

HP EliteBook 8570p Specifications

General IconGeneral
Bus typeDMI
SteppingL1
Tjunction105 °C
Processor cache3 MB
Processor cores2
Processor modeli5-3230M
System bus rate5 GT/s
Processor familyIntel® Core™ i5
Processor seriesIntel Core i5-3200 Mobile series
Processor socketBGA 1023
Processor threads4
Processor codenameIvy Bridge
Processor frequency2.6 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version3.0
Processor boost frequency3.2 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)35 W
CPU multiplier (bus/core ratio)26
Maximum number of PCI Express lanes16
Motherboard chipsetIntel® QM77 Express
Internal memory4 GB
Memory clock speed1600 MHz
Internal memory typeDDR3-SDRAM
Maximum internal memory- GB
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi
Card reader integratedYes
Total storage capacity500 GB
Number of HDDs installed1
Display diagonal15.6 \
Display resolution1366 x 768 pixels
Native aspect ratio16:9
On-board graphics card ID0x166
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 4000
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1100 MHz
LightScribe-
Intel segment taggingEnterprise
Audio systemSRS PS PRO
WWANNot installed
Data networkNot supported
Wi-Fi standards802.11a, 802.11b, 802.11g
Bluetooth version4.0
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity0
Pointing deviceTouchpad
Operating system installedWindows 8 Pro
Form factorClamshell
Product typeLaptop
Product colorSilver
Country of originChina
Processor codeSR0WX
Processor ARK ID72056
Processor package size31 x 24 (BGA1023) mm
Supported instruction setsAVX
Intel Identity Protection Technology version1.00
Battery capacity62 Wh
Battery life (max)8.25 h
Number of battery cells6
AC adapter power65 W
AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
Sustainability certificatesEPEAT Gold, ENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth251 mm
Width374 mm
Height34 mm
Weight2610 g
