12.
If it is necessary to replace the display hinges:
NOTE: Substeps a through e apply to an HP EliteBook 8570p Notebook PC computer model.
See substeps f through i for display hinge removal procedures for an HP EliteBook 6570b
Notebook PC computer model.
a. Remove the display hinges from the display enclosure.
b. Remove the two Phillips PM2.0×3.0 screws that hold the display hinge assembly together.
c. Remove the display hinge inner cover (2).
d. Remove the display hinge end cap (3).
140 Chapter 4 Removal and replacement procedures
