Spare part number Description
612757-001 HP essential nylon case
628664-001 3-cell, 31-Wh, 2.80-Ah, Li-ion battery
628668-001 6-cell, 62-Wh, 2.80-Ah, Li-ion battery
628670-001 6-cell, 55-Wh, 2.80-Ah, Li-ion battery
628824-001 Modem module (does not include the modem module cable)
NOTE: The modem module cable is included in the Cable Kits, spare part numbers 686308-001
(for use only on HP EliteBook 8570p Notebook PC computer models) and 686307-001 (for use
only on HP ProBook 6570b Notebook PC computer models).
631243-001 9-cell, 100-Wh, 3.0-Ah, Li-ion battery
631954-001 Intel Centrino Advanced-N 6205 WLAN module
633252-001 750-GB, 7200-rpm, 9.5-mm hard drive (does not include hard drive bracket or screws)
NOTE: The hard drive bracket and screws are included in the Hard Drive Hardware Kit, spare
part number 644694-001.
634089-001 6-cell, 73-Wh, 2.20-Ah, Li-ion battery
634400-001 HP un2430 EV-DO/HSPA Mobile Broadband Module
634862-001 320-GB, 7200-rpm, 9.5-mm hard drive (does not include hard drive bracket or screws)
NOTE: The hard drive bracket and screws are included in the Hard Drive Hardware Kit, spare
part number 644694-001.
634925-001 500-GB, 7200-rpm, 9.5-mm hard drive (does not include hard drive bracket or screws)
NOTE: The hard drive bracket and screws are included in the Hard Drive Hardware Kit, spare
part number 644694-001.
641182-001 Base enclosure for use only on HP EliteBook 8570p Notebook PC computer models (includes rubber
feet, service cover release latch assembly, and battery release latch assembly)
641186-001 Speaker assembly (includes cable)
641190-001 Plastics Kit for use only on HP EliteBook 8570p Notebook PC computer models (includes service
cover with “made in China” label, optical drive bay space saver, ExpressCard bay space saver,
and wireless antenna cable covers)
641191-001 Screw Kit for use only on HP EliteBook 8570p Notebook PC computer models
641192-001 Rubber Kit for use only on HP EliteBook 8570p Notebook PC computer models (includes display
bezel left and right rubber screw covers, base enclosure front and rear rubber screw covers, top
cover rubber bumper)
641193-001 Display Hinge Kit for use only on HP EliteBook 8570p Notebook PC computer models (includes left
and right hinges, brackets, hinge covers, and hinge caps)
641207-001 Top cover for use only on HP EliteBook 8570p Notebook PC computer models equipped with a
pointing stick and a fingerprint reader (includes TouchPad)
641208-001 Top cover for use only on HP EliteBook 8570p Notebook PC computer models equipped with a
pointing stick but not a fingerprint reader (includes TouchPad)
641369-001 4-GB memory module (PC3, 12800, 1600-MHz)
Sequential part number listing
53

HP EliteBook 8570p Specifications

General

Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-3230M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-3200 Mobile series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	2.6 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	26
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM77 Express
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	500 GB
Number of HDDs installed	1
Display diagonal	15.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0x166
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
LightScribe	-
Intel segment tagging	Enterprise
Audio system	SRS PS PRO
WWAN	Not installed
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 8 Pro
Form factor	Clamshell
Product type	Laptop
Product color	Silver
Country of origin	China
Processor code	SR0WX
Processor ARK ID	72056
Processor package size	31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery capacity	62 Wh
Battery life (max)	8.25 h
Number of battery cells	6
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth	251 mm
Width	374 mm
Height	34 mm
Weight	2610 g
