HP EliteBook 8570p User Manual

Spare part number Description
686314-001 USB board
686315-001 Smart Card reader board (for use only on HP ProBook 6570b Notebook PC computer models)
686316-001 Top cover for use only on HP ProBook 6570b Notebook PC computer models equipped with a
pointing stick and a fingerprint reader (includes TouchPad)
686317-001 Top cover for use only on HP ProBook 6570b Notebook PC computer models equipped with a
pointing stick but not a fingerprint reader (includes TouchPad)
686318-001 Keyboard with pointing stick for use on HP EliteBook 8570p Notebook PC computer models
equipped with the Windows 7 operating system in the United States (includes keyboard cable and
pointing stick cable)
686318-031 Keyboard with pointing stick for use on HP EliteBook 8570p Notebook PC computer models
equipped with the Windows 7 operating system in the United Kingdom and Singapore (includes
keyboard cable and pointing stick cable)
686318-041 Keyboard with pointing stick for use on HP EliteBook 8570p Notebook PC computer models
equipped with the Windows 7 operating system in Germany (includes keyboard cable and pointing
stick cable)
686318-051 Keyboard with pointing stick for use on HP EliteBook 8570p Notebook PC computer models
equipped with the Windows 7 operating system in France (includes keyboard cable and pointing
stick cable)
686318-061 Keyboard with pointing stick for use on HP EliteBook 8570p Notebook PC computer models
equipped with the Windows 7 operating system in Italy (includes keyboard cable and pointing
stick cable)
686318-071 Keyboard with pointing stick for use on HP EliteBook 8570p Notebook PC computer models
equipped with the Windows 7 operating system in Spain (includes keyboard cable and pointing
stick cable)
686318-081 Keyboard with pointing stick for use on HP EliteBook 8570p Notebook PC computer models
equipped with the Windows 7 operating system in Denmark (includes keyboard cable and pointing
stick cable)
686318-091 Keyboard with pointing stick for use on HP EliteBook 8570p Notebook PC computer models
equipped with the Windows 7 operating system in Norway (includes keyboard cable and pointing
stick cable)
686318-131 Keyboard with pointing stick for use on HP EliteBook 8570p Notebook PC computer models
equipped with the Windows 7 operating system in Portugal (includes keyboard cable and pointing
stick cable)
686318-141 Keyboard with pointing stick for use on HP EliteBook 8570p Notebook PC computer models
equipped with the Windows 7 operating system in Turkey (includes keyboard cable and pointing
stick cable)
686318-151 Keyboard with pointing stick for use on HP EliteBook 8570p Notebook PC computer models
equipped with the Windows 7 operating system in Greece (includes keyboard cable and pointing
stick cable)
686318-161 Keyboard with pointing stick for use on HP EliteBook 8570p Notebook PC computer models
equipped with the Windows 7 operating system in Latin America (includes keyboard cable and
pointing stick cable)
56 Chapter 3 Illustrated parts catalog

HP EliteBook 8570p Specifications

General

Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-3230M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-3200 Mobile series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	2.6 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	26
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM77 Express
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	500 GB
Number of HDDs installed	1
Display diagonal	15.6 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0x166
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
LightScribe	-
Intel segment tagging	Enterprise
Audio system	SRS PS PRO
WWAN	Not installed
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 8 Pro
Form factor	Clamshell
Product type	Laptop
Product color	Silver
Country of origin	China
Processor code	SR0WX
Processor ARK ID	72056
Processor package size	31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery capacity	62 Wh
Battery life (max)	8.25 h
Number of battery cells	6
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth	251 mm
Width	374 mm
Height	34 mm
Weight	2610 g
