HP EliteBook 8740W Service Guide

Processor
NOTE: The processor spare part kit includes replacement thermal material.
Description Spare part number
Intel Quad Core i7-940XM Extreme 2.13-GHz processor, 8-MB L2 cache, 8 threads, 55W 619342-001
Intel Quad Core i7 920XM Extreme 2.00-GHz (turbo up to 3.20-GHz) processor, 8-MB L2 cache, 8
threads, 55-W
590663-001
Intel Quad Core i7-840QM 1.86-GHz processor, 8-MB L2 cache, 8 threads, 45W 612260-001
Intel Quad Core i7 820QM 1.73-GHz (turbo up to 3.06-GHz) processor, 8-MB L2 cache, 8 threads,
45-W
583053-001
Intel Quad Core i7-740QM 1.73-GHz processor, 6-MB L2 cache, 8 threads, 45W 612259-001
Intel Quad Core i7 720Qm 1.66-GHz (turbo up to 2.80-GHz) processor, 8-MB L2 cache, 8 threads,
45-W
586170-001
Intel Dual Core i7-640M 2.80-GHz (turbo up to 3.46-GHz) processor, 4-MB L2 cache, 4 threads,
35W
625826-001
Intel Dual Core i7 620M 2.66-GHz (turbo up to 3.33-GHz) processor, 4-MB L2 cache, 4 threads,
35-W
587259-002
Intel Dual Core i5-580M 2.66-GHz (turbo up to 3.33-GHz) processor, 3-MB L2 cache, 4 threads,
35W
625825-001
Intel Dual Core i5-560M 2.66-GHz (turbo up to 3.20-GHz) processor, 3-MB L2 cache, 4 threads,
35W
625824-001
Intel Dual Core i5 540M 2.53-GHz (turbo up to 3.06-GHz) processor, 3-MB L2 cache, 4 threads,
35-W
594188-002
Intel Dual Core i5 520M 2.40-GHz (turbo up to 2.93-GHz) processor, 3-MB L2 cache, 4 threads,
35-W
594187-002
Before removing the processor, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 47), and then remove the following components:
a. Keyboard (see
Keyboard on page 63)
b. Switch cover (see
Switch cover on page 67)
c. Graphics board heat sink (see
Graphics board heat sink on page 69)
d. Processor heat sink (see
Processor heat sink on page 73)
Component replacement procedures 75
Downloaded from LpManual.com Manuals

HP EliteBook 8740W Specifications

General

Internal memory	8 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	32 GB
Motherboard chipset	Intel® QM57 Express
Bus type	DMI
Stepping	B1
Tjunction	100 °C
Processor cache	6 MB
Processor cores	4
Processor model	i7-720QM
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-700 Mobile Series
Processor socket	Socket 988
Processor threads	8
Processor codename	Clarksfield
Processing Die size	296 mm²
Processor frequency	1.6 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.8 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8
Thermal Design Power (TDP)	45 W
CPU multiplier (bus/core ratio)	12
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	774 M
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	Blu-Ray DVD Combo
Card reader integrated	Yes
Total storage capacity	500 GB
Display diagonal	17 \
Display resolution	1920 x 1200 pixels
Native aspect ratio	16:10
Discrete graphics card model	NVIDIA® Quadro® FX 2800M
Maximum graphics card memory	1.024 GB
Type	PC
Modem speed	56 Kbit/s
Power supply type	AC/DC
Wireless technology	Wi-Fi
Graphics card family	NVIDIA
Intel segment tagging	Enterprise
Compatible operating systems	Windows 7
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Audio system	HD
Number of built-in speakers	2
Pointing device	Touchpad + Scroll zone
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
CardBus PCMCIA slots quantity	0
Cable lock slot type	Kensington
Password protection type	HDD
AC adapter power	200 W
Certification	ISV
Product type	Mobile workstation
Product color	Black
Country of origin	China
Processor code	SLBLY
Processor ARK ID	43122
Processor package size	37.5 x 37.5 mm
Supported instruction sets	SSE4.2
Intel® Turbo Boost Technology	1.0
