HP EliteBook Folio 9470m Specification

1. Power connector 4. Headphone/Microphone combo port
2. Security lock slot 5. Smart Card Reader
3. USB 3.0 charging port
At A Glance
Windows 8 Pro, Windows 7 versions or FreeDOS
Magnesium display enclosure, magnesium-reinforced chassis, wear-resistant platinum-colored HP DuraFinish, HP DisplaySafe
frame, HP DuraKeys, precision metal-alloy hinges, aluminum keyboard deck, and chemically strengthened glass touchpad
Choice of 3rd Generation Intel® Core™ i7 and i5 with Turbo Boost Technology
Integrated Intel® HD Graphics 4000
14.0-inch diagonal HD or HD+ widescreen LED-backlit display
Choice of 7200 rpm user-removable hard drive (up to 500 GB) with HP 3D DriveGuard, 500 GB 7200 rpm Self Encrypting Hard
Drive, 256 GB Self Encrypting Solid State Drive, 240 GB Solid State Drive, 128 GB Solid State Drive, 180 GB Solid State Drive, or
256 GB mSATA Solid State Drive
Optional 32 GB mSATA Flash Cache module support for Intel Smart Response Technology. (Available only with standard non-SED
hard drive).
Built-in docking for a desktop-like experience
DisplayPort for high resolution support
SRS PRO Audio™ optimized for high fidelity audio during video conferencing and web-based training
4-cell (52 WHr) HP Long Life battery and 6-cell (60WHr) HP Long Life slice battery for extended battery life
Glass touchpad with chemically etched surface and pointstick
Integrated Smart Card Reader and configurable fingerprint reader for strong security authentication
HP Premier Image with Microsoft Security Essentials and without trialware
Flexible wireless connectivity options:
Optional integrated wireless mobile broadband 3G and 4G/LTE support (no Win 8 support)
Integrated Intel Centrino® 802.11 a/b/g/n 2x2 + BT Combo 4.0 HS, 802.11 a/b/g/n 2x2 + BT Combo 4.0 HS or 802.11 b/g/n
2x2 + BT Combo 4.0 HS
Low Halogen*, ENERGY STAR qualified (with Microsoft OS) and EPEAT Gold registered in the U.S. (with Microsoft OS). EPEAT
status varies by country- please see epeat.net .
* Meeting the industry definition of 'Low Halogen' per the iNEMI Position Statement on "Low Halogen" Electronics. Plastic parts
incorporated into the chassis generally contain < 1000 ppm (0.1%) of bromine or chlorine. Printed circuit board and substrate
laminates generally contain < 1500 ppm (0.15%) of total bromine and chlorine. Service parts after purchase may not be Low Halogen.
External accessories, including power supplies, power cords, and peripherals as well as the following customer-configurable internal
component: ATT SIM card, are not Low Halogen.
QuickSpecs
HP EliteBook Folio 9470m
Overview
DA - 14317 North America — Version 10 — August 15, 2013 Page 2

HP EliteBook Folio 9470m Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Sand
Country of origin	China
Market positioning	Business
Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-3427U
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-3400 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	1.8 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.8 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	17 W
CPU multiplier (bus/core ratio)	18
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM77 Express
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	1 x 4 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Card reader integrated	Yes
Total storage capacity	180 GB
Compatible memory cards	SD
Number of SSDs installed	1
Display surface	Matt
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0x166
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	350 MHz
On-board graphics card dynamic frequency (max)	1150 MHz
Audio system	SRS PRO
Wi-Fi standards	-
Bluetooth version	4.0
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Pointing device	DualPoint
Recovery operating system	Windows 8 Pro
Operating system installed	Windows 7 Professional
Processor code	SR0N7
Processor ARK ID	64903
Processor package size	31 x 24 mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery capacity	52 Wh
Battery life (max)	- h
AC adapter power	45 W
Sustainability certificates	EPEAT Silver, ENERGY STAR

Weight and Dimensions

Depth	231 mm
Width	338 mm
Height	18.9 mm
Weight	1610 g
