g.
Fan/heat sink assembly (see
Fan/heat sink assembly on page 55)
h. System board (see
System board on page 57)
i.
Hinge cover and hinge cap (see
Hinge cover on page 59)
Remove the display assembly:
1. Remove the two Phillips PM2.0×5.0 screws (1) that secure the display assembly to the top cover.
2. Slide the display assembly (2) away from the top cover and remove it.
Reverse this procedure to install the display assembly.
62 Chapter 4 Removal and replacement procedures
