HP EliteBook Revolve 810 G1 User Manual

Using HP Software Setup
HP Software Setup can be used to reinstall drivers or select software that has been corrupted or deleted
from the system.
1. From the Start screen, type HP Software Setup, and select Apps.
2. Open HP Software Setup.
3. Follow the on-screen directions to reinstall drivers or select software.
Windows 7
To protect your information, use Windows Backup and Restore to back up individual files and folders,
back up your entire hard drive (select models only), create system repair discs (select models only) with
the installed optical drive (select models only) or an optional external optical drive, or create system
restore points. In case of system failure, you can use the backup files to restore the contents of
your computer.
Windows Backup and Restore provides the following options:
●
Creating a system repair disc (select models only) by using the installed optical drive (select
models only) or an optional external optical drive
●
Backing up your information
●
Creating a system image (select models only)
●
Scheduling automatic backups (select models only)
●
Creating system restore points
●
Recovering individual files
●
Restoring the computer to a previous state
●
Recovering information using recovery tools
NOTE: For detailed instructions, perform a search for these topics in Help and Support.
In case of system instability, HP recommends that you print the recovery procedures and save them for
later use.
NOTE: Windows includes the User Account Control feature to improve the security of your computer.
You may be prompted for your permission or password for tasks such as installing software, running
utilities, or changing Windows settings. See Help and Support for more information.
Windows 7
75

HP EliteBook Revolve 810 G1 Specifications

General

Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor code	SR0XH
Processor cache	4 MB
Processor cores	2
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-3600 Mobile series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Motherboard chipset	Intel® QM77 Express
Processor frequency	2.1 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	31 mm
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.3 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x8, 1x16, 2x4, 2x8
Supported instruction sets	AVX
Thermal Design Power (TDP)	17 W
CPU multiplier (bus/core ratio)	21
Thermal Monitoring Technologies	Yes
Maximum number of PCI Express lanes	16
Memory slots	1x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	mSATA
Storage media	SSD
Total storage capacity	256 GB
Compatible memory cards	MicroSD (TransFlash)
Number of HDDs installed	0
Number of SSDs installed	1
Display diagonal	11.6 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0x166
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	350 MHz
On-board graphics card dynamic frequency (max)	1200 MHz
Keyboard layout	-
Processor ARK ID	71258
Audio system	DTS Studio Sound
3G standards	HSPA+
Data network	3G
Wi-Fi standards	802.11a, 802.11b, 802.11g
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Bundled software	HP ePrint\\r CyberLink MediaSuite\\r HP Page Lift\\r PDF Complete Corporate Edition\\r Adobe Flash Player
Operating system installed	Windows 8 Pro
Form factor	Convertible (Swivel)
Product type	Hybrid (2-in-1)
Product color	Silver
Country of origin	China
Intel Identity Protection Technology version	1.00
Battery capacity	44 Wh
Battery life (max)	8.25 h
Number of battery cells	6
AC adapter power	45 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	285 mm
Width	212 mm
Height	22.2 mm
Weight	1400 g
