Figure 7 Disconnect Speaker cable from the MB
Fig
ure 8 Disconnect ODD/HDD PSU cables from the MB
Figure 9 Disconnect MB PSU cable from the MB Figure 10 Disconnect other PSU cables from the MB
Figure 11 Disconnect CPU Power cable from the MB
Fig
ure 12 Disconnect HDD Power cable from HDD
To Next Page
