HP EliteDisplay E233 User Manual

EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01
including liquids, semi-liquids (gel/paste) and toner
chambers, and service stations.
Components and waste containing asbestos
0
Components, parts and materials containing
refractory ceramic fibers
0
Components, parts and materials containing
radioactive substances
0
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Screw driver
Ph2/Ph0
Disassembly Tool (Better)
Bolt screwdriver
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Take out the monitor and external cable from carton, then put them onto the desk horizontally, separate stand from
monitor as picture.
2. Remove the bucket screws
3. Use disassemble tool to separate back cover from monitor (started from the disassembiing hole as the first picture).
4. Taking off the LVDS cable and Lightbar cable firstly,then separate USB cover and chassis , (use screwdiver to
disassemble screws as picture).
5. Taking off PI mylar,disassemble power board and IF board screws ,as the VGA bolt screws.
6. Separatingchassis assy all parts as picture.
7. SeparatingMid frame and panel , Use screwdriver to remove nine screwszel.
8.
9.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).

HP EliteDisplay E233 Specifications

General

3D	No
Pixel pitch	0.265 x 0.265 mm
Screen shape	Flat
Display diagonal	23 \
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	50 - 60 Hz
Horizontal scan range	30 - 80 kHz
Viewable size, vertical	286.4 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509.2 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800, 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+)
On/off switch	Yes
Sustainability certificates	EPEAT Gold, ENERGY STAR
Product color	Black, Silver
Country of origin	China
Market positioning	Business
Pivot angle	0 - 90 °
Tilt angle range	-5 - 23 °
Number of OSD languages	10
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, DUT, ENG, ESP, FRE, ITA, JPN, POR
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Number of upstream ports	1
USB Type-A downstream ports quantity	2
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	100 - 240 V
Energy efficiency scale	A++ to E
Power consumption (max)	36 W
Annual energy consumption	25 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	19 W
Cables included	AC, DisplayPort, HDMI, VGA
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	218 mm
Height (with stand)	457.9 mm
Weight (with stand)	5800 g
Depth (without stand)	44.7 mm
Width (without stand)	521 mm
Height (without stand)	311.7 mm
Weight (without stand)	3290 g
