Taking off the
LVDS cable and
Lightbar cable
firstly,then
separate USB
cover and
chassis , (use
screwdiver to
disassemble
screws as
picture).
Taking off
PI
mylar,disassem
ble power
board and IF
board
screws ,as the
VGA bolt
screws.
