Page #5 background imageLoading...
Page #5 background image
Altitude - Non-operating
0 to 12,192 m
(0 to 40,000 ft)
White LED Backlights
Yes
CCFL Panel
No
Arsenic-Free Display
Glass
Yes
Low Halogen
4
Yes, except external cables
Mercury-Free Display
Backlighting
Yes
Environmental Data
Eco-Label Certifications
& Declarations
This product has received or is in the process of being certified to the following
approvals and may be labeled with one or more of these marks:
IT ECO declaration
US ENERGY STAR®
TCO 6.0
EPEAT® Gold registered in the United States. See
http://www.epeat.net
for
registration status in your country
Energy Consumption
(in accordance with US
ENERGY STAR® test
method)
115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation
19.20 W 19.60 W 19.10 W
Sleep
0.23 W 0.29 W 0.22 W
Off
0.20 W 0.27 W 0.20 W
Heat Dissipation
*
115VAC, 60 Hz 230VAC, 50 Hz 100VAC, 60 Hz
Normal Operation
66 BTU/hr 67 BTU/hr 65 BTU/hr
Sleep
1 BTU/hr 1 BTU/hr 1 BTU/hr
Off
1 BTU/hr 1 BTU/hr 1 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one
hour.
Additional Information
This product is in compliance with the Restrictions of Hazardous
Substances (RoHS) directive - 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive - 2002/96/EC.
This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
This product is in compliance with the IEEE 1680 (EPEAT) standard at the
Gold level, see
www.epeat.net
Plastics parts weighing over 25 grams used in the product are marked per
ISO 11469 and ISO1043.
This product contains 18.2 % post-consumer recycled plastic (by wt.)
This product is 98.6 % recycle-able when properly disposed of at end of
life.
QuickSpecs
HP EliteDisplay E241i 24-inch IPS LED Backlit Monitor
Technical Specifications
DA - 14807 Worldwide — Version 2 — February 17, 2014
Page 5

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteDisplay E241i and is the answer not in the manual?

HP EliteDisplay E241i Specifications

General IconGeneral
Pixel pitch0.27 x 0.27 mm
Response time8 ms
Display diagonal24 \
Display resolution1920 x 1200 pixels
Display technologyLED
Contrast ratio (dynamic)5000000:1
Contrast ratio (typical)1000:1
Display number of colors-
Display brightness (typical)250 cd/m²
HDCPYes
USB hub version2.0
HDMI ports quantity0
USB Type-A downstream ports quantity3
Product colorSilver
Country of originChina
Market positioningBusiness
Tilt angle range-5 - 30 °
Panel mounting interface100 x 100 mm
AC input voltage90 - 265 V
Power consumption (max)40 W
Power consumption (standby)0.5 W
Power consumption (typical)35 W
Sustainability certificatesEPEAT Gold, ENERGY STAR
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)25 - 85 %
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)276.2 mm
Height (with stand)516.56 mm
Depth (without stand)55 mm
Width (without stand)556 mm
Height (without stand)362.6 mm
Weight (without stand)6580 g
