HP ElitePad 1000 G2 Quickspecs

QuickSpecs
HP ElitePad 1000 G2
Technical Specifications
Worldwide — Version 1.1 — February, 2014 Page 21
Output current limit
1.1A
Connector
3 pin/grounded, mates with interchangeable cords; 70 pin / tyco connector
(to tablet side)
Environmental Design
Operating
temperature
32° to 95° F (0° to 35° C)
Non-operating (storage)
temperature
-4° to 185° F (-20° to 85° C)
Operating altitude
0 to 16,404 ft (0 to 5,000 m)
Non-operating altitude
0 to 50,000 ft (0 to 15,240 m)
Humidity
0% to 95%
Storage Humidity
0% to 95%
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives; Worldwide safety
standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals
- C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class
B, CCC, NOM-1 NYCE
HP 2-cell (30 WHr)
Polymer Long Life
Primary battery
Weight
0.17 kg
Dimensions (H x W x L)
8.7 x 1.56 x 0.17 in
(22.09 x 13.963 x 0.43 cm)
Cells/Type
2-cell, Lithium Ion Polymer
Energy
Voltage
7.4V
Amp-hour capacity
4.2
Watt-hour capacity
30Wh
Temperature
Operating (Charging)
32˚ to 113˚ F (0˚ to 45˚ C)
Operating (Discharging)
14˚ to 140˚ F(-10˚ to 60˚ C)
Non-operating
-4˚ to 140˚ F (-20˚ to 60˚ C)
Battery Re-Charge Time
System in OFF or Standby
Mode
depends on system setting
System ON
depends on system setting
Fuel Gauge LED
No
Warranty
36 months
Optional Travel Battery
Available
No
ENVIRONMENTAL DATA
MATERIAL USAGE
This product does not contain any of the following substances in excess of regulatory limits (for reference of these limits please
refer to the HP General Specification of the Environment
(http://www.hp.com/hpinfo/globalcitizenship/environment/supplychain/gen_specifications.html):
• Asbestos

HP ElitePad 1000 G2 Specifications

General

Stepping	C0
Processor code	SR1SK
Processor cache	2 MB
Processor cores	4
System bus rate	- GT/s
Processor family	Intel Atom®
Processor series	Intel Atom Z3700 Series
Processor codename	Bay Trail
Processor frequency	1.59 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor package size	17 x 17 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor boost frequency	2.39 GHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	22 nm
Scenario Design Power (SDP)	2 W
Device type	Tablet PC
Form factor	Slate
Product color	Silver
Internal memory	4 GB
Memory clock speed	1067 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	SSD
Card reader integrated	No
Compatible memory cards	Not supported
Internal storage capacity	64 GB
Display diagonal	10.1 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1920 x 1200 pixels
Native aspect ratio	16:10
Graphics card	HD Graphics
Rear camera type	Single camera
Rear camera resolution (numeric)	8 MP
Front camera resolution (numeric)	2.1 MP
Battery capacity	30 Wh
Battery life (max)	13 h
Number of battery cells	2
Audio system	DTS Sound+
AC adapter power	10 W
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Platform	Windows
Bundled software	Buy Office PDF Complete Corporate Edition HP Mobile Connect HP Wireless Hotspot (models with WLAN) HP ePrint HP Manageability HP PageLift HP Support Assistant HP SoftPaq Download Manager Kindle Box (50 GB offer)
Operating system version	-
Operating system installed	Windows 8.1 Pro
HDMI ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Country of origin	China
Processor ARK ID	80267
Processor socket	BGA 1380

Weight and Dimensions

Depth	178 mm
Width	261 mm
Height	9.2 mm
Weight	680 g
