HP FlexFabric 5700 User Manual

22
Configuration procedure
1. Create VPN instances on the MCE and PE 1, and bind the VPN instances to VLAN interfaces.
For the configuration procedure, see "Configure the VPN instances on the MCE and PE 1:."
2. Config
ure routing between the MCE and VPN sites:
# Enable an OSPF process on the devices in the two VPNs, and advertise the subnets. (Details
not shown.)
# Configure OSPF on the MCE, and bind OSPF process 10 to VPN instance vpn1 to learn the
routes of VPN 1.
<MCE> system-view
[MCE] ospf 10 router-id 10.10.10.1 vpn-instance vpn1
[MCE-ospf-10] area 0
[MCE-ospf-10-area-0.0.0.0] network 10.214.10.0 0.0.0.255
[MCE-ospf-10-area-0.0.0.0] quit
[MCE-ospf-10] quit
# Display the routing table of VPN 1 on the MCE.
[MCE] display ip routing-table vpn-instance vpn1
Destinations : 13 Routes : 13
Destination/Mask Proto Pre Cost NextHop Interface
0.0.0.0/32 Direct 0 0 127.0.0.1 InLoop0
10.214.10.0/24 Direct 0 0 10.214.10.3 Vlan10
10.214.10.0/32 Direct 0 0 10.214.10.3 Vlan10
10.214.10.3/32 Direct 0 0 127.0.0.1 InLoop0
10.214.10.255/32 Direct 0 0 10.214.10.3 Vlan10
127.0.0.0/8 Direct 0 0 127.0.0.1 InLoop0
127.0.0.0/32 Direct 0 0 127.0.0.1 InLoop0
127.0.0.1/32 Direct 0 0 127.0.0.1 InLoop0
127.255.255.255/32 Direct 0 0 127.0.0.1 InLoop0
192.168.0.0/24 OSPF 10 2 10.214.10.2 Vlan10
224.0.0.0/4 Direct 0 0 0.0.0.0 NULL0
224.0.0.0/24 Direct 0 0 0.0.0.0 NULL0
255.255.255.255/32 Direct 0 0 127.0.0.1 InLoop0
The output shows that the MCE has learned the private route of VPN 1 through OSPF process
10.
# On the MCE, bind OSPF process 20 to VPN instance vpn2 to learn the routes of VPN 2. The
configuration procedure is similar to that for OSPF process 10.
The output shows that the MCE has learned the private route of VPN 2 through OSPF:
[MCE] display ip routing-table vpn-instance vpn2
Destinations : 13 Routes : 13
Destination/Mask Proto Pre Cost NextHop Interface
0.0.0.0/32 Direct 0 0 127.0.0.1 InLoop0
10.214.20.0/24 Direct 0 0 10.214.20.3 Vlan20
10.214.20.0/32 Direct 0 0 10.214.20.3 Vlan20
10.214.20.3/32 Direct 0 0 127.0.0.1 InLoop0
10.214.20.255/32 Direct 0 0 10.214.20.3 Vlan20

HP FlexFabric 5700 Specifications

General

Category	Switch
Power Device	Internal power supply
Model	FlexFabric 5700
Uplink Ports	4 x 10 Gigabit SFP+
Form Factor	Rack-mountable
Routing Protocol	OSPF, BGP, RIP, IS-IS, PIM, IGMP, VRRP, RIPng, OSPFv3, PIM6
Remote Management Protocol	SNMP, CLI
Features	IPv6 support, ACL, QoS, VLAN, LLDP, sFlow, RMON
Compliant Standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3x
Power Redundancy	Yes
Operating Temperature	0 °C to 45 °C
Operating Humidity	10% to 90% non-condensing
MAC Address Table Size	32K entries
