HP FlexFabric 5700 User Manual

35
Step Command Remarks
8. (Optional.) Configure
filtering of advertised
routes.
filter-policy
acl6-number
export
[ protocol
process-id ]
By default, BGP does not filter
advertised routes.
9. (Optional.) Configure
filtering of received
routes.
filter-policy
acl6-number
import
By default, BGP does not filter
received routes.
Displaying and maintaining IPv6 MCE
Execute display commands in any view.
Task Command
Display information about a
specified VPN instance or all VPN
instances.
display ip vpn-instance
[
instance-name
vpn-instance-name ]
Display BGP peer group
information for a VPN instance.
display bgp group ipv6
[
unicast
]
vpn-instance
vpn-instance-name [
group-name
group-name ]
Display BGP peer information for a
VPN instance.
display bgp peer ipv6
[
unicast
]
vpn-instance
vpn-instance-name
[ ipv6-address prefix-length | { ipv6-address |
group-name
group-name }
log-info
| [ [ ipv6-address ]
verbose
] [
standby slot
slot-number ] ]
For commands that display information about a routing table, see Layer 3—IP Routing Command
Reference.
For more information about the display bgp group and display bgp peer commands, see Layer
3—IP Routing Command Reference.
IPv6 MCE configuration example
Network requirements
As shown in Figure 6, RIPng runs in VPN 2. Configure the MCE device to separate routes from
different VPNs and advertise VPN routes to PE 1 through OSPFv3.

HP FlexFabric 5700 Specifications

General

Category	Switch
Power Device	Internal power supply
Model	FlexFabric 5700
Uplink Ports	4 x 10 Gigabit SFP+
Form Factor	Rack-mountable
Routing Protocol	OSPF, BGP, RIP, IS-IS, PIM, IGMP, VRRP, RIPng, OSPFv3, PIM6
Remote Management Protocol	SNMP, CLI
Features	IPv6 support, ACL, QoS, VLAN, LLDP, sFlow, RMON
Compliant Standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3x
Power Redundancy	Yes
Operating Temperature	0 °C to 45 °C
Operating Humidity	10% to 90% non-condensing
MAC Address Table Size	32K entries
