3. Remove the LED board and cable (3).
Reverse this procedure to install the LED board and cable.
Display assembly
NOTE: The display assembly spare part kit includes webcam, two microphones, and wireless
antenna transceivers and cables).
Description Spare part number
14.0-in, HD, LED, BrightView display assembly
In butter gold finish 641343-001
In charcoal gray finish 641338-001
In luminous rose finish 641337-001
In ocean drive finish 639447-001
In Pacific blue finish 641340-001
In pearl pink finish 641341-001
In pewter finish 641339-001
In Sonoma red finish 641336-001
In sweet purple finish 641342-001
In Nero black finish 677167-001
Before removing the display assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
88 Chapter 4 Removal and replacement procedures
