TABLE 6-1. PARTS LIST (Continued)
Reference Mfr
Designation
HP Part Number Qty Description
Code
Mfr Part Number
R222 0684-1041 R:FXD COMP 100K OHM 10% 1/4W 01121 CB 1041
R223 2100-2682 R:VAR WW 10K OHM 10% LIN 2W 28480 2100-2682
R224 07035-80730 1 SLIDEWIRE ASSY:5K OHM 28480 07035-80730
R224 5060-4570 1 WIPER X-AXIS 28480 5060-4570
R225 0757-0427 1 R:FXD MET FLM 1.5K OHM 1% 1/8W 28480 0757-0427
R226 2100-2289 R:VAR 1K ± 20% 2W 28480 2100-2289
R227 0683-1055 R:FXD COMP 1 MEGOHM 5% 1/4W 01121 CB 1055
R228 0683-4731 R:FXD COMP 47K OHM 10% 1/4W 01121 CB 4731
R229 0683-2025 R:FXD COMP 2000 OHM 5% 1/4W 01121 CB 2025
R230 0683-2025 R:FXD COMP 2000 OHM 5% 1/4W 01121 CB 2025
R231 0684-2731 R:FXD COMP 27K OHM 10% 1/4W 01121 CB 2731
R232 0684-4731 R:FXD COMP 47K OHM 10% 1/4W 01121 CB 4731
R233 0683-1055 R:FXD COMP 1 MEGOHM 5% 1/4W 01121 CB 1055
R234 0684-1541 R:FXD COMP 150K OHM 10% 1/4W 01121 CB 1541
R235 0684-1541 R:FXD COMP 150K OHM 10% 1/4W 01121 CB 1541
R236 0699-0001 R:FXD COMP 2.7 OHM 10% 1/2W 01121 EB 27G1
R237 2100-1729 R:VAR WW 10 OHM 20% LIN 2W 28480 2100-1729
R238 0684-4741 R:FXD COMP 470K OHM 10% 1/4W 01121 CB 4741
R239 0684-1031 R:FXD COMP 10K OHM 10% 1/4W 01121 CB 1031
R240 0684-4741 R:FXD COMP 470K OHM 10% 1/4W 01121 CB 4741
R241 0684-1831 R:FXD COMP 18K OHM10% 1/8W 01121 CB 1831
R242 0684-3331 R:FXD COMP 33K OHM 10% 1/4W 01121 CB 3331
R243 0683-3945 R:FXD COMP 390K OHM 5% 1/4W 01121 CB 3945
R244 0684-4731 R:FXD COMP 47K OHM 10% 1/4W 01121 CB 4731
R245 0683-2225 R:FXD COMP 2.2K OHM 5% 1/4W 01121 CB 2225
R246 0684-6811 R:FXD COMP 680 OHM 10% 1/4W 01121 CB 6811
R247 0684-1841 R:FXD COMP 180K OHM 10% 1/4W 01121 CB 1841
R248 0684-1041 R:FXD COMP 100K OHM 10% 1/4W 01121 CB 1041
R249 0684-1021 R:FXD COMP 1000 OHM 10% 1/4W 01121 CB 1021
R250 0684-3331 R:FXD COMP 33K OHM 10% 1/4W 01121 CB 3331
R251 0684-1021 R:FXD COMP 1000 OHM10%1/4W 01121 CB 1021
R252 0684-4711 R:FXD COMP 470 OHM 10% 1/4W 01121 CB 4711
R253 0684-1521 R:FXD COMP 1500 OHM 10% 1/4W 01121 CB 1521
R254 0683-4725 R:FXD COMP 4700 OHM 5% 1/4W 01121 CB 4725
R255 0813-0046 R:FXD WW 1 OHM 10% 3W 28480 0813-0046
R256 0683-6215 R:FXD COMP 620 OHM 5% 1/4W 01121 CB 6215
R257 0761-0049 R:FXD MET OX 200 OHM 5% 1W 28480 0761-0049
R258 0683-6215 R:FXD COMP 620 OHM 5% 1/4W 01121 CB 6215
R259 0761-0049 R:FXD MET OX 200 OHM 5% 1W 28480 0761-0049
R301 0684-6831 4 R:FXD COMP 68K OHM 10% 1/4W 01121 CB 6831
R302 0684-6831 R:FXD COMP 68K OHM 10% 1/4W 01121 CB 6831
R303 0684-6831 R:FXD COMP 68K OHM 10% 1/4W 01121 CB 6831
R304 0684-6831 R:FXD COMP 68K OHM10% 1/4W 01121 CB 6831
R401 0811-1202 1 R:FXD WW 50 OHM 5% 3W 28480 0811-1202
R501 0683-6845 I
R:FXD 680K ±5% 1/4W
28480 0683-6845
R502 0698-8754 2
R:FXD 10 MEG ±1% 1/4W
28480 0698-8754
R503 0698-8754 2
R:FXD 10 MEG ±1% 1/4W
28480 0698-8754
R601 NOT USED
R602 2100-1621 1 R:VAR 5K WW 4W 28480 2100-1621
S101 3130-0166 2 SECTION:ROTARY SWITCH 28480 3130-0166
S201 3130-0166 SECTION:ROTARY SWITCH 28480 3130-0166
S401 3101-1702 2 SWITCH:TOGGLE SPDT 18911 8926K124
S501 3101-1702 SWITCH:TOGGLE SPDT 18911 8926K124
S601 3101-2404 1 SWITCH:TOGGLE SPDT 82389 11A-1242
S602 3101-1174 1 SWITCH:TOGGLE SPDT 18911 7511K4
T601 5060-6857 TRANSFORMER ASSEMBLY
V101 1990-0072 4 PHOTOCONDUCTOR:2-LEAD, T0-5 PACKAGE 28480 1990-0072
V102 1990-0072 PHOTOCONDUCTOR:2-LEAD, T0-5 PACKAGE 28480 1990-0072
V201 1990-0072 PHOTOCONDUCTOR:2-LEAD, T0-5 PACKAGE 28480 1990-0072
V202 1990-0072 PHOTOCONDUCTOR:2-LEAD, T0-5 PACKAGE 28480 1990-0072
R504 0698-3453 2 R:FXD 196K ±1% 1/8W 28480 0698-3453
R505 0698-3453 2 R:FXD 196K ±1% 1/8W 28480 0698-3453
See introduction to this section for ordering information
6-5
