TABLE 6-2. MISCELLANEOUS PARTS
Circuit Mfr Part
Symbol
Part No. Description Typical Mfr
No.
MECHANICAL, ELECTRICAL, ETC.
1251-0293 Connector, 24-pin (mate for J-602) Amphenol 57-30240
1400-0084 Fuse holder Littlefuse 342004
17999-06494 Pulley, Drive cable (white plastic) H-P 17999-06494
17999-06460 Spring, Cable tension H-P 17999-06460
17999-16046 Clamp and Pad Assy (for shipping) H-P 17999-16046
4040-0011 Dust Cover (plastic) Allen Plastic
5080-3627 X Axis Stringing Kit H-P 5080-3627
1251-0148 Receptacle, Power, Cord Tower Mfg. H-1061 I.G.
1500-0043 Belt, Drive, clutch (mylar) Kinelogic Corp.
5080-3635 Lubricant Slidewire H-P 5080-3635
8120-1378 Power cord, 7.5 ft. Belden KMS-7041
5060-0761 Foot, Stacking H-P 50600761
0703501660 Bracket
8120-039 Spectrastrip (9 conductor)(Y-axis trailing Spectrastrip
cable)
1490-0080 Shorting Links (Guard Straps) H-P 1490-0080
07035-01020 Panel Control (English) H-P 07035-01020
07035-62260 Hood Assembly (Standard)
07035-01030 Panel Control (Metric) H-P 07035-01030
07035-01000 Panel, Side, RH and LH H-P 07035-01000
07004-01860 Panel, front, rear H-P 07004-01860
07035-61440 Cable Assembly
07035-00511 Cover, Bottom H-P 07035-00511
07035-61660 Rear Hood Assy (Standard) H-P 07035-61660
07035-61670 Rear Hood Assy (Metric) H-P 07035-61670
07035-64270 Hood Assembly (Metric) Option 001
07004-60640 Solenoid, Pen lit (Serial Prefix 826 and below H-P
require index pointer 07005-00730)
07035-62160 Clutch Assy, X-axis H-P 07035-62160
07035-81000 Table, Electrostatic H-P 07035-81000
07035-80730 Slidewire, X-axis H-P 07035-80730
07035-81020 Shipping Carton H-P 07035-81020
09125-20350 Plunger Assembly, solenoid H-P
ACCESSORY KIT, PAPER, INK
07035-82660 Accessory Kit H-P 0703-82660
508-1190 Pen, Disposable, Red H-P 5081-1990
5081-1191 Pen, Disposable, Blue H-P 5081-1191
5081-1192 Pen, Disposable, Green H-P 5081-1192
5081-1193 Pen, Disposable, Black H-P 5081-1193
9270-1006 Chart Paper, Standard (heavy) Gubelman H-10070/A
9270-1007 Chart Paper, Standard (light) Gubelman L-10070/A
9270-1023 Chart Paper, Metric (heavy) Gubelman
9270-1027 Chart Paper, Metric (light) Gubelman
KNOBS
0370-0025 Zero & Vernier Control H-P 03700025
0370-0112 Attenuator H-P 03700112
