TABLE 1-1. MODEL 7035B SPECIFICATIONS
PERFORMANCE
Input Range: 1, 10, 100 mV/in.; 1 and 10 V/in. (Option 001,
Metric calibration: 0.4, 4, 40, 400 mV/cm and
4 V/cm). Continuous vernier between ranges.
Type of Input: Floated and guarded signal pair. Input may be
operated up to ±500 Vdc with respect to chassis ground.
Signal and guard terminals are available at the front panel
or at a rear connector. Mating rear connector supplied.
Input Resistance:
Range Input Resistance:
1 mV/in. (0.4 mV/cm) Potentiometric.
(essentially in-
finite at null)
Variable 11k
10 mV/in. (4 mV/cm) 100k
Variable 100k
100 mV/in. (40 mV/cm) 1 meg
Variable 1 meg
1 V/in. (400 mV/cm) 1 meg
Variable 1 meg
10V/in. (4 V/cm) 1 meg
Variable 1 meg
Maximum Allowable Source Resistance: 20k ohm on most
sensitive range, no restriction on other ranges.
Normal Mode Rejection (at line frequency): > 30 dB (18
dB/octave roll-off above 60 Hz).
Common Mode Rejection: Conditions for the following data are
DC or line frequency AC with up to 1K ohm between the
positive input and negative input, and the negative input
connected to the guard terminal. Maximum allowable DC
or DC plus peak AC common mode voltage is 500V.
Range
Standard Metric DC (CMR) AC (CMR)
1 mV/in. 0.4 mV/cm 130 dB 100 dB
10 mV/in. 4 mV/cm 110 dB 80 dB
100 mV/in. 40 mV/cm 90 dB 60 dB
1V/in. 400 mV/cm 70 dB 40 dB
10 V/in. 4 V/cm 50 dB 20 dB
Slewing Speed 20 in/s, 50 cm/, nominal at 115V line.
Accuracy: ±0.2% of full scale.
Linearity: ±0.1% of full scale.
Resettability: ±0.1% of full scale
Reference Stability: Continuous electronic zener reference with
temperature stability better than 0.002%/degrees C.
Zero Set: Zero may be placed anywhere on the writing area or
electrically off scale up to one full scale from zero index.
Adjustable by a locking ten-turn, high resolution control.
GENERAL
Writing Mechanism: Servo actuated ink pen.
Writing Area: 7 in. X 10 in. (18 cm X 25 cm).
Paper Holddown: Autogrip electric paper hold-down grips
charts 8-1/2 in. X 11 in. or smaller. Special paper is not
required.
Pen Lift: Electric pen lift with provision for remote control.
Power: 115 or 230 V ± 10%, 50 to 60 Hz, approximately 45 W.
Weight: Net, 18 lb (8 kg; shipping, 24 lb (10.9 kg)
1-2
