HP J8697A - Page 28

20
Installing the Modules
Figure 6. Example: Module being installed
Figure 7. Module fully installed
Insert module into the guides
and slide it in until it is fully
inserted.
Open extractor handles
Then tighten the retaining screws
on the module until they are secure,
but do not overtighten them.
Use the extractor handles to
seat the module completely.
