HP J8697A Installation Guide

33
Specifications
Network Connectivity Speeds and Technologies
Table 1. Optional Network Connectivity, Speeds and Technologies
Transceiver Form-Factor and Connector
1
Speed Technology
Cabling
SFP ("mini-GBIC")
Connector
X2
Connector
SFP+
Connector
100 Mbps
100-FX Fiber (multimode) LC
100-BX Fiber (single mode) LC
1 Gbps
1000-T Copper (twisted-pair) RJ-45
1000-SX Fiber (multimode) LC
1000-LX Fiber (multimode or single mode) LC
1000-LH Fiber (single mode) LC
1000-BX Fiber (single mode) LC
10 Gbps
10-Gig CX4 Copper (twinaxial) CX4
10-Gig
Direct Attach
Copper (twinaxial) Not
Applicable
10-Gig SR
Fiber (multimode) SC
LC
10-Gig LRM Fiber (multimode) SC
LC
10-Gig LR Fiber (single mode) SC LC
10-Gig ER
Fiber (single mode) SC LC
1
For supported transceivers, visit www.hp.com/networking/support.
– In the first textbox, type J4858 (for 100-Mb and Gigabit information), or J8436 (for 10-Gigabit information).
– Select any of the products that display in the dropdown list.
– Select P
roduct support information. The
n click on Manuals and find the Transceiver Support Matrix.
For technical details of cabling and technologies see "Cabling and Technology Specifications" on page 36.

HP J8697A Specifications

General

Ports	24
Form Factor	Rack-mountable
Power Supply	Internal
Management	Managed
VLAN Support	Yes
Jumbo Frame Support	Yes
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Model	HP J8697A
Port Type	10/100/1000BASE-T
Layer	Layer 2
