HP L1502 LCD
GENERAL PRODUCT SPECIFICATION
15 inch LCD MONITOR
TYPE:AJ6S50/02
BRAND : HP (L1502)
8639 000 15367
2004-04-23
2004-04-23
590
14
18
HP WU
Go to cover page
5.7 Panel Defect Limits
This is general specification from HP, if any deviation, HP agree to follow
up panel specification.
Table 9 lists the countable and rejectable sizes for each type of commonly found
defects.
Defects within the countable size are allowed; however, the total number
of countable defects shall not exceed the maximum number of all countable defects
noted in the table. Any defect with dimensions greater than the countable defect
shall be sufficient cause for rejecting the display.
The symbols used are: D = Diameter, L = Length (longest dimension), W = Width
(perpendicular to the length), N = Number or Count, Spot = Contamination, S =
Separation from Edge to Edge, Dot = Sub-pixel stuck on/off (electrical).
TABLE 9
OPTO-MECHANICALDEFECTS
VISUALDEFECTS: (See Notes) COUNT REJECT
Dark/White Spot
0.25 < D £ 0.40,N£ 3
D > 0.40 or N > 3
Bright Line (Light Lint)
0.03 <W£ 0.152, L £ 2.03,N£ 4
W>0.152 or L > 2.03 or N > 4
Dark Line (Dark Lint/Hair)
0.03 <W£ 0.10, 0.3 < L £ 1.0,N£ 4
W>0.10 or L > 1.0 or N > 4
Polarizer Scratch
0.01 <W£ 0.07, 1.0 < L £ 10.0,N£ 3
W>0.07orL > 10.0 or N > 3
Polarizer Dents
0.15 < D £ 0.4,N£ 3
D > 0.4 or N > 3
Polarizer Bubble
0.254 < D £ 0.40,N£ 3
D > 0.40 or N > 3
Rubbing Defects Not Allowed
Newton Rings Not Allowed
Mottling Not Allowed
ELECTRICALDEFECTS: (See Notes)
Bright Dot (Electrical):
High and Low Level (Total)
N £ 3
N>3
Dark Dot (Electrical)
N £ 5
N>5
Minimum Distance Between Electrical Defects
High Level Green to High Level Green
S ³ 25.4
S<25.4
Bright Dots: High Level to High Level
S ³ 15
S<15
Bright Dots: High Level to Low Level and
Low Level to Low Level
S ³ 5
S<5
Bright Dots: Two Adjacent Low Level
and Low Level (Any Plane)
N £ 2
N>2
Bright Dots Three or More Adjacent High or Low
Level (Horizontal Plane)
Not Allowed
Dark Dots
S ³ 15
S<15
Dark Dots: Two Adjacent (Horizontal
Plane Only)
N £ 2
N>2
Dim Lines Not Allowed
Cross Line(s) On/Off Not Allowed
Horizontal Line(s) On/Off Not Allowed
Vertical Lines(s) On/Off Not Allowed
Minimum Distance Between ANY
Allowable Defects
S ³ 25
(Unless Otherwise Specified
S<25
Maximum No. of Allowable Defects
N £ 5 (all types)
N>5
