GENERAL PRODUCT SPECIFICATION
Go to cover page
15 inch LCD MONITOR
TYPE : AJ6S50/02
BRAND : HP(L1502)
8639 000 15367
2004-04-23
2004-04-23
590
15
18
HP WU
HP L1502 LCD64
6. Audio
No audio function for HP L1502.
7. Mechanical characteristics
7.1 Tilt base
Tilt angle: -5 ° to +30 °
7.2 Shipping and Packing
Packaging and wrapping shall be sufficient to protect the product against
damage or loss during shipment from the supplier to the destination
specified in the purchase order.
7.2.1 Unit Dimension / Weight
Set Dimension (incl. Pedestal): W340mm x D185.3mm x H338mm.
New weight: 3.6 Kg
7.2.2 Shipping Dimension / Weight
Carton Dimension: W400mm x D123mm x H414mm.
Gross Weight: 4 Kg
7.2.3 Pallet / Block Unit
It use two kind of pallets, which mixed into container (see sheet 560 for
the detail).
Thesizeis,
A type pallet: 1135 x 820 x 120 mm.
For see shipments,
A type pallet: 90 packages per pallet (18 layers x 5 packages per
layer).
The package count for sea shipping container shall be:
40 Ft Container:
90 packages per pallet x 28 Pallets = 2520 packages.
Total packagers: 1080+720=1800 packages.
20 Ft Container:
90 packages per pallet x 14 Pallets = 1260 packages.
Total packagers: 1260 packages
TABLE 10. Shipping and Packing Dimensions
HP L1502
Drop specs level 2 (36" height) 2C+2E+6F
Attached base
