HP L1530 - LCD Flat Panel Monitor User Manual

Technical Specifications
L1730 Model
17-inch Flat Panel Monitor
Display
Type
17.0 in.
TFT LCD
43.18 cm
Viewable Image Size 17.0-inch diagonal 43.18 cm
Maximum Weight
(Unpacked)
15.43 lb. 7 kg (unpacked)
Dimensions (include pedestal)
Height (adjustable)
Depth
Width
13.94 to 16.46 in.
9.65 in.
15 in.
354 to 418 mm
245 mm
381 mm
Preferred Mode 1280 x 1024 (60 Hz)
Text Mode 720 x 400
Dot Pitch 0.264 (H) x 0.264 (W) mm
Horizontal Frequency 30 to 83 kHz
Vertical Refresh Rate 56 to 76 Hz
Environmental Requirements
Temperature:
Operating Temperature
Non-operating Temperature
41 to 95
o
F
-4 to 140
o
F
5 to 35
o
C
--20 to +60
o
C
Relative Humidity 20 to 80%
Altitude:
Operating
Non-operating
0 to 12,000 ft.
0 to 40,000 ft.
0 to 3657.6 m
0 to 12192 m
Power Source 100 – 240 VAC, 50 – 60 Hz
User’s Guide B-3
