HP L2045W User Manual

Icon Main Menu Submenu Description
9300 K Changes to slightly blueish white.
6500 K Changes to slightly reddish white.
Custom Color Selects and adjusts your own color scales:
●
R—sets your own red color levels
●
G—sets your own green color levels
●
B—sets your own blue color levels
sRGB Sets your screen colors to adapt to the color standards used in
the image technology industry.
Language Selects the language in which the OSD menu is displayed. The
factory default is English.
Management Selects the power management features of the monitor.
Power Saver Enables the power saving feature. Select:
●
On
●
Off
The factory default is On.
Power On Recall Restores power to the monitor following an unexpected removal
of power. Select:
●
On
●
Off
The factory default is On.
Mode Display Displays the resolution, refresh rate and frequency information
on the screen each time the OSD Main Menu is accessed.
Select:
●
On
●
Off
The factory default is Off.
Power-On Status
Display
Displays the operating status of the monitor each time the
monitor is powered on. Select the location to display the status
to:
●
Top
●
Middle
●
Bottom
●
Off
The factory default is Top.
Table 4-2 OSD Menu (continued)
ENWW Adjusting the Monitor Settings 25

HP L2045W Specifications

General

Pivot angle	0 - 90 °
Plug and Play	Yes
Tilt angle range	-5 - 30 °
Height adjustment	-
Panel mounting interface	100 x 100 mm
Pixel pitch	0.258 x 0.258 mm
Aspect ratio	16:10
Display diagonal	20.1 \
Display resolution	1680 x 1050 pixels
Vertical scan range	50 - 76 Hz
Horizontal scan range	24 - 93 kHz
Contrast ratio (typical)	800:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	2 W
Power consumption (typical)	60 W
Storage temperature (T-T)	-34 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Certification	Australian ACA Approval, Canadian Requirements/CSA, CE Marking, CISPR Requirements, Energy Star Compliant, German Ergonomic (TUV and GS Mark), ISO 9241-3, 7, 8 VDT Guidelines, ISO 13406-2 Pixel Defect Guidelines, MPR-II Compliant, PC2001 Certified, S. Korea
Product color	Silver
Country of origin	China
USB hub version	2.0
HDMI ports quantity	0
USB Type-A downstream ports quantity	3

Weight and Dimensions

Depth (with stand)	223 mm
Width (with stand)	479 mm
Weight (with stand)	7800 g
Depth (without stand)	75 mm
Width (without stand)	315 mm
Height (without stand)	471 mm
Weight (without stand)	7680 g
