HP Laser Jet 3390

c.) Pull the tab out and then rotate tab forward to release white retaining collar and remove left collar
d.) Follow step c.) for right retaining collar but DO NOT REMOVE. Slide the pickup roller to the left to
release right side of the pickup roller and remove.
e.) Remove two screws on the separation pad assembly. Lift the separation pad assembly straight up to
remove. Replace pad
