Installing a DIMM (memory)
247
4
Position the DIMM chip in front of the
slot located inside the I/O door. The
gold contacts should be pointing
toward the printer and the cutouts
should be at the top and bottom.
5
Carefully press the DIMM chip into
the slot, making sure that it is
straight and all the way in (A). The
cam latches, located at the top and
bottom, should rotate inward. To
snap the cam latches into place,
press the handles toward each
other (B).
4
5
