Clearing paper jams
109
9
Replace the fuser, left side first. Be
sure to push the fuser firmly into the
printer.
10
Lock the fuser in place by rotating
the levers to the horizontal position.
11
Replace the rear output bin, left side
first.
12
Plug the power cord into the printer.
13
Replace the tray 2 dust cover or the
optional duplexer.
14
Turn the printer back on.
15
If a paper jam message persists,
there is still paper in the printer. Look
for paper in another location (see
“Paper jam locations” on page 97).
Note
Since the printer has been turned off,
you will need to send the print job again.
