4. Extend the paper guides fully (callout 1) and then load the media stack into tray 1 (callout 2). Adjust
the paper guides to the size of the paper.
NOTE: Place the media into tray 1 with the side to be printed on face-up and the top toward the
product.
Load tray 2 or 3
1. Pull the tray out of the product.
2. Slide open the paper length and width guides.
●
To load Legal-size paper, extend the tray by pressing and holding the extension tab while
pulling the front of the tray toward you.
NOTE: When it is loaded with Legal-size paper, the tray extends from the front of the product
approximately 64 mm (2.5 inches).
ENWW Load paper and print media 51
