Low-voltage power supply (LVPS)
CAUTION: ESD sensitive assembly.
Before proceeding, remove the following assemblies:
●
Left cover. See
Left cover on page 55.
Remove the LVPS
WARNING! When removing the low-voltage power supply ( callout 1), do not touch the electric
element (callout 2) as shown. Be sure to hold the bottom side of the low-voltage power supply.
1
2
186 Chapter 1 Removal and replacement ENWW
