3. Replacement fuser gear assembly: Release two tabs in the order shown below
(callouts 1 and 2). and then remove the spacer (callout 3).
Original fuser gear assembly: Installation complete—this step is not required.
Figure 1-302 Install a replacement fuser gear assembly (3 of 3)
1
2
3
218 Chapter 1 Removal and replacement ENWW
