HP LASERJET ENTERPRISE 700 COLOR MFP M775dn - PD pickup assembly cassette 1

1x500 right-front cover
1. Take the cassette out of the feeder, and then open the right door.
2. Remove one screw (callout 1), and then remove the right-front cover (callout 2).
Figure 1-306 Remove the 1x500 right-front cover
2
1
