HCI rear cover
Before proceeding, remove the following assemblies:
●
HCI left tray. See
HCI left tray on page 265.
●
HCI left cover. See
HCI left cover on page 266.
Remove the HCI rear cover
Release two tabs (callout 1), and then remove the rear cover (callout 2).
Figure 1-365 Remove the HCI rear cover
2
1
270 Chapter 1 Removal and replacement ENWW
