HP LASERJET ENTERPRISE 700 COLOR MFP M775dn - Page 305

2. Release two tabs (callout 1), slide the right rear cover (callout 2) in the direction indicated and
remove it from the right center cover.
Figure 1-372 Remove the HCI right center cover and right rear cover (2 of 2)
2
1
ENWW
Input devices
275
