Document feeder mylar strips
TIP: Before removing the mylar strips, take note of how they are positioned on the document jam
access door and the inside bottom edge of the document feeder cover.
1. Open the document feeder cover.
Figure 1-19 Remove the document feeder mylar strips (1 of 3)
2. Lift up the jam access door, and carefully remove the mylar strip.
Figure 1-20 Remove the document feeder mylar strips (2 of 3)
14 Chapter 1 Removal and replacement ENWW
