Alphabetical parts list
Table 2-20 Alphabetical parts list
Description Part number Table and page
Cartridge-tray assembly RM2-5299-000 Internal assemblies (1 of 7)
on page 119
Cassette, Tray 2 RM2-5469-000 Internal assemblies (3 of 7)
on page 123
Color misregistration sensor assembly RM1-8029-000 Internal assemblies (2 of 7)
on page 121
Cover, DIMM RC4-2852-000 Covers on page 117
Cover, left RL1-3063-000 Covers on page 117
Cover, lower-rear RC3-1700-000 Internal assemblies (7 of 7)
on page 131
Cover, rear (simplex model) RL1-3072-000 Internal assemblies (6 of 7)
on page 129
Cover, right RC4-2855-000 Covers on page 117
Cover, right front RC4-2860-000 Covers on page 117
Cover, top assembly RM2-5300-000 Covers on page 117
Cover, upper-rear RL1-3068-000 Internal assemblies (7 of 7)
on page 131
DC controller RM2-8028-000 PCAs on page 133
Door, front assembly RM2-5301-000 Covers on page 117
Door, rear RM1-8052-000 Internal assemblies (7 of 7)
on page 131
Door, rear (simplex model) RC3-1665-000 Internal assemblies (6 of 7)
on page 129
Driver PCA RM1-8032-000 PCAs on page 133
Fan RK2-3847-000 Internal assemblies (4 of 7)
on page 125
Fax PCA (Brazil only) CF208-60001 PCAs on page 133
Fax PCA (Europe only) CF207-60001 PCAs on page 133
Fax PCA (US only) CF206-60001 PCAs on page 133
Feed guide, duplex assembly (includes transfer roller)
1
RM1-4879-000 Internal assemblies (7 of 7)
on page 131
Feed motor assembly RM1-5419-000 Internal assemblies (5 of 7)
on page 127
Fixing assembly (110v) RM2-5476-000 Internal assemblies (5 of 7)
on page 127
Fixing assembly (220v) RM2-5478-000 Internal assemblies (5 of 7)
on page 127
136 Chapter 2 Parts and diagrams ENWW
