Table 2-20 Alphabetical parts list (continued)
Description Part number Table and page
Fixing motor assembly RM1-8609-000 Internal assemblies (5 of 7)
on page 127
Formatter PCA M476 dn CF386-60002 PCAs on page 133
Formatter PCA M476 dn (China only) CF386-60003 PCAs on page 133
Formatter PCA M476 dw CF387-60004 PCAs on page 133
Formatter PCA M476 dw (China only) CF387-60005 PCAs on page 133
Formatter PCA M476 nw CF385-60001 PCAs on page 133
Formatter PCA M476 nw (China only) CF385-60002 PCAs on page 133
High-voltage power supply RM1-8031-000 PCAs on page 133
Intermediate transfer belt (ITB) RM2-0192-000 Internal assemblies (2 of 7)
on page 121
Low-voltage power supply (110v) RM2-8030-000 PCAs on page 133
Low-voltage power supply (220v) RM2-8032-000 PCAs on page 133
Motor, developer DC (M1) RL1-3053-000 Internal assemblies (4 of 7)
on page 125
Motor, drum DC (M2) RL1-1800-000 Internal assemblies (4 of 7)
on page 125
Multi purpose clutch assembly RM1-8318-000 Internal assemblies (3 of 7)
on page 123
Multi purpose tray assembly RM1-8610-000 Internal assemblies (3 of 7)
on page 123
Pad, separation Tray 1 RL1-1785-000 Internal assemblies (3 of 7)
on page 123
Paper delivery assembly RM1-8049-000 Internal assemblies (5 of 7)
on page 127
Paper feed guide assembly (includes transfer roller) RM1-8043-000 Internal assemblies (7 of 7)
on page 131
Paper feed guide assembly (simplex model; includes transfer roller) RM1-8043-000 Internal assemblies (6 of 7)
on page 129
Paper pickup assembly RM1-8045-000 Internal assemblies (3 of 7)
on page 123
Paper-pickup guide assembly RM1-8051-000 Internal assemblies (7 of 7)
on page 131
Registration assembly RM1-4841-000 Internal assemblies (3 of 7)
on page 123
Reverse drive assembly RM1-4880-000 Internal assemblies (7 of 7)
on page 131
Rib assembly, rear-door RM1-8053-000 Internal assemblies (7 of 7)
on page 131
Roller, paper-pickup Tray 1 RL1-1802-000 Internal assemblies (2 of 7)
on page 121
ENWW Alphabetical parts list 137
