Numerical parts list
Table 2-21 Numerical parts list
Part number Description Table and page
1150-7951 Wireless controller PCA PCAs on page 133
CE863–67901 Tray 3 feeder assembly main body (includes paper cassette) 250-sheet paper feeder
accessory kit (optional Tray 3)
on page 135
CF206-60001 Fax PCA (US only) PCAs on page 133
CF207-60001 Fax PCA (Europe only) PCAs on page 133
CF208-60001 Fax PCA (Brazil only) PCAs on page 133
CF385-60001 Formatter PCA M476 nw PCAs on page 133
CF385-60002 Formatter PCA M476 nw (China only) PCAs on page 133
CF386-60002 Formatter PCA M476 dn PCAs on page 133
CF386-60003 Formatter PCA M476 dn (China only) PCAs on page 133
CF387-60004 Formatter PCA M476 dw PCAs on page 133
CF387-60005 Formatter PCA M476 dw (China only) PCAs on page 133
CF387-60106 Scanner assembly/ADF Scanner and document feeder
main assembly on page 115
RC3-1665-000 Door, rear (simplex model) Internal assemblies (6 of 7)
on page 129
RC3-1700-000 Cover, lower-rear Internal assemblies (7 of 7)
on page 131
RC4-2852-000 Cover, DIMM Covers on page 117
RC4-2855-000 Cover, right Covers on page 117
RC4-2860-000 Cover, right front Covers on page 117
RK2-3847-000 Fan Internal assemblies (4 of 7)
on page 125
RL1-1785-000 Pad, separation Tray 1 Internal assemblies (3 of 7)
on page 123
RL1-1800-000 Motor, drum DC (M2) Internal assemblies (4 of 7)
on page 125
RL1-1802-000 Roller, paper-pickup Tray 1 Internal assemblies (2 of 7)
on page 121
RL1-3053-000 Motor, developer DC (M1) Internal assemblies (4 of 7)
on page 125
RL1-3063-000 Cover, left Covers on page 117
RL1-3068-000 Cover, upper-rear Internal assemblies (7 of 7)
on page 131
RL1-3072-000 Cover, rear (simplex model) Internal assemblies (6 of 7)
on page 129
ENWW Numerical parts list 139
