Table 2-21 Numerical parts list (continued)
Part number Description Table and page
RM1-4840-000 Tray 2 separation roller assembly Internal assemblies (3 of 7)
on page 123
RM1-4841-000 Registration assembly Internal assemblies (3 of 7)
on page 123
RM1-4879-000
Feed guide, duplex assembly (includes transfer roller)
1
Internal assemblies (7 of 7)
on page 131
RM1-4880-000 Reverse drive assembly Internal assemblies (7 of 7)
on page 131
RM1-5419-000 Feed motor assembly Internal assemblies (5 of 7)
on page 127
RM1-5420-000 Solenoid, Tray 1 (MP) Internal assemblies (2 of 7)
on page 121
RM1-8029-000 Color misregistration sensor assembly Internal assemblies (2 of 7)
on page 121
RM1-8031-000 High-voltage power supply PCAs on page 133
RM1-8032-000 Driver PCA PCAs on page 133
RM1-8043-000 Paper feed guide assembly (simplex model; includes transfer roller) Internal assemblies (6 of 7)
on page 129
RM1-8043-000 Paper feed guide assembly (includes transfer roller) Internal assemblies (7 of 7)
on page 131
RM1-8045-000 Paper pickup assembly Internal assemblies (3 of 7)
on page 123
RM1-8047-000 Tray 2 paper pickup roller assembly Internal assemblies (3 of 7)
on page 123
RM1-8049-000 Paper delivery assembly Internal assemblies (5 of 7)
on page 127
RM1-8051-000 Paper-pickup guide assembly Internal assemblies (7 of 7)
on page 131
RM1-8052-000 Door, rear Internal assemblies (7 of 7)
on page 131
RM1-8053-000 Rib assembly, rear-door Internal assemblies (7 of 7)
on page 131
RM1-8318-000 Multi purpose clutch assembly Internal assemblies (3 of 7)
on page 123
RM1-8544-000 Tray 3 paper cassette only 250-sheet paper feeder
accessory kit (optional Tray 3)
on page 135
RM1-8609-000 Fixing motor assembly Internal assemblies (5 of 7)
on page 127
RM1-8610-000 Multi purpose tray assembly Internal assemblies (3 of 7)
on page 123
RM2-0192-000 Intermediate transfer belt (ITB) Internal assemblies (2 of 7)
on page 121
140 Chapter 2 Parts and diagrams ENWW
