HP LaserJet Pro CP1025 - Color Printer - Formatter and wireless PCA (plus model)

Formatter and wireless PCA (plus model)
CAUTION: ESD sensitive.
Before proceeding, remove the following components:
●
Right cover assembly. See
Right cover assembly on page 18.
●
Left cover assembly. See
Left cover assembly on page 19.
●
Top door assembly. See
Top door assembly on page 20.
Remove the formatter and wireless PCA (plus model)
1. Release two tabs (callout 1), and then remove the wireless PCA (callout 2).
Figure 1-50 Remove the formatter and wireless PCA (plus model; 1 of 2)
1
2
44 Chapter 1 Removal and replacement ENWW
