Locations of major assemblies
Figure 2-6 External assembly locations
1
2
3
4
5
5
9
10
11
12
8
7
6
Item Description Item Description
1 Top cover assembly 7 Lower rear cover
2 Right cover assembly 8 Rear cover assembly
3 Right handle cover 9 Multi-purpose tray cover
4 Right front cover 10 Cartridge door assembly
5 Left cover 11 Output bin
6 Power receptacle 12 Face-down cover
