QuickSpecs
HP LP2065 20-inch LCD
Monitor
Technical Specifications
Worldwide — Version 6 — September 25, 2007 Page 3
Anti-Static Yes
Default Color Temperature 6500 K
Plug and Play Yes
Self Powered USB 2.0
Hub
One upstream, four downstream ports (cable included)
Input Signal Two DVI-I connectors (dual VGA analog or dual digital input possible)
Input Impedance 75 ohms ± 10%
Sync Input Separate sync (HSYNC/VSYNC); composite sync, Sync on Green
Video Cable Two VGA to DVI-I; two DVI-D to DVI-I
Video/Other Inputs
Video Cable Length 6.5 ft (1.98 m)
Input Power Auto-Ranging, 90 ~ 265 VAC; internal power supply, 50 Hz/60 Hz
Frequency 47.5 to 63 Hz
Typical Power
Consumption
55 watts (without USB ports); 70 watts (USB ports fully loaded)
Maximum < 75 watts
Power Saving < 2 watts
Power
Power Cable Length 5.9 ft (1.8 m)
Unpacked w/stand 16.7 to 21.8 x 17.4 x 8.67 in
(42.5 to 55.5 x 44.3 x 22.0 cm)
Unpacked w/o stand
(head only)
13.58 x 17.4 x 3.42 in
(34.5 x 44.3 x 8.7 cm)
Dimensions (H x W x D)
Packaged 11.77 x 22.2 x 16.77 in
(29.9 x 56.4 x 42.6 cm)
Unpacked With stand: 20.28 lbs (9.2 kg);
Without stand: 12.65 lbs (5.75 kg)
Weight
Packaged 26.3 lb (11.95 kg)
Tilt Range -5° to + 25° vertical
Swivel Range -45° to + 45°
Height Adjustable Yes, range 5.1 in (13.0 cm)
Pivot Rotation Yes
Mechanical
Base Detachable, ships detached
Temperature - Operating 41° to 95° F (5° to 35° C)
Temperature - Non-
operating
6° to 140° F (-10° to 60° C)
Humidity - Operating 20% to 80% non-condensing
Humidity - Non-operating 20% to 80%
Altitude - Operating +12,000 ft (3657.6 m)
Environmental
Altitude - Non-operating +40,000 ft (12,192 m)

HP LP2065 Specifications

General

3D	Yes
Pixel pitch	0.255 x 0.255 mm
Response time	8 ms
Display diagonal	20.1 \
Display resolution	1600 x 1200 pixels
Vertical scan range	48 - 85 Hz
Horizontal scan range	30 - 94 kHz
Contrast ratio (dynamic)	-
Contrast ratio (typical)	800:1
Display brightness (typical)	300 cd/m²
USB hub version	2.0
DVI-I ports quantity	2
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	5
LED indicators	Power
Tilt angle range	-5 - 25 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (standby)	2 W
Power consumption (typical)	75 W
Storage temperature (T-T)	10 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Certification	TCO'03, TUV-Ergo, UL, VCCI, CE, ISO 13406-2
Country of origin	China
Market positioning	Business

Weight and Dimensions

Depth (with stand)	220 mm
Height (with stand)	425 mm
Weight (with stand)	9200 g
Depth (without stand)	87 mm
Width (without stand)	443 mm
Height (without stand)	345 mm
Weight (without stand)	5750 g
