HP LP2065 User Manual

QuickSpecs
HP LP2065 20-inch LCD
Monitor
Technical Specifications
Worldwide — Version 6 — September 25, 2007 Page 2
Type 20-inch Active Matrix TFT (thin film transistor)
Viewable Image Area
(diagonal)
20.1 in (51 cm)
Screen Opening
(W x H)
16.2 x 12.17 in (40.8 x 30.6 cm)
Viewing Angle (typical)
1
178° horizontal/178° vertical (10:1 minimum contrast ratio)
Brightness (typical)
1
300 nits (cd/m
2
)
Contrast Ratio (typical)
1
800:1
Response Time (typical)
1
8 ms
2
Pixel Pitch 0.255 mm
Backlight Lamp Life
(to half brightness)
45K hours
Panel
Bezel Width 16 mm
Buttons or Switches OSD menu select, auto adjust/OSD up, OSD down
Input select, power
Languages English, French, German, Spanish, Italian, Dutch, and Japanese
On Screen Display
(OSD) Controls
User Controls Brightness, contrast, positioning, color temperature, individual color
control, serial number display, full screen resolutions, clock, clock phase,
input selection, image control (including scaling), and factory reset
Horizontal Frequency 30 to 94 kHz (VGA input); 30 to 92 KHz (DVI input for modes with pixel
clock less than 162 MHz)
Vertical Frequency 48 to 85 Hz (VGA input); 48 to 85 Hz (DVI input for modes with pixel
clock less than 162 MHz)
Native Resolution 1600 x 1200 @ 60 Hz (recommended)
1600 x 1200 @ 60 Hz, 75 Hz (analog input)
1280 x 1024 @ 60 Hz, 75 Hz, and 85 Hz
1280 x 960 @ 60 Hz
1152 x 900 @ 66 Hz
1024 x 768 @ 60 Hz, 75 Hz, and 85 Hz
800 x 600 @ 60 Hz, 85 Hz
Preset VESA Graphic
Modes (non-interlaced)
640 x 480 @ 60 Hz, 75 Hz, and 85 Hz
Text Mode 720 x 400 @ 70 Hz
Mac Mode 1152 x 870 @ 75 Hz and 832 x 624 @ 75 Hz
Sun Mode 1152 x 900 @ 66 Hz
Maximum Pixel Clock
Speed
202 MHz (analog input); 162 MHz (DVI input)
User Programmable
Modes
Yes, 10
Signal Interface/
Performance
Anti-Glare Yes
1
All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or
lower.
2
Response time: 8 ms (gray to gray); 16 ms (rise and fall).

HP LP2065 Specifications

General

3D	Yes
Pixel pitch	0.255 x 0.255 mm
Response time	8 ms
Display diagonal	20.1 \
Display resolution	1600 x 1200 pixels
Vertical scan range	48 - 85 Hz
Horizontal scan range	30 - 94 kHz
Contrast ratio (dynamic)	-
Contrast ratio (typical)	800:1
Display brightness (typical)	300 cd/m²
USB hub version	2.0
DVI-I ports quantity	2
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	5
LED indicators	Power
Tilt angle range	-5 - 25 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (standby)	2 W
Power consumption (typical)	75 W
Storage temperature (T-T)	10 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Certification	TCO'03, TUV-Ergo, UL, VCCI, CE, ISO 13406-2
Country of origin	China
Market positioning	Business

Weight and Dimensions

Depth (with stand)	220 mm
Height (with stand)	425 mm
Weight (with stand)	9200 g
Depth (without stand)	87 mm
Width (without stand)	443 mm
Height (without stand)	345 mm
Weight (without stand)	5750 g
