Table 2-19 Numerical parts list (continued)
Part number Description Table and page
CZ165-60109 Scanner assembly (M177 model)
Scanner and document feeder
main assemblies (M177 model)
on page 119
CZ165-60110 ADF top cover assembly
Document feeder assembly
(M177 model) on page 123
CZ165-60111 ADF base
Document feeder assembly
(M177 model) on page 123
CZ165-60112 Auto document feeder assembly
Scanner and document feeder
main assemblies (M177 model)
on page 119
CZ165-60115 Scan bezel assembly
Scanner assembly (M177 model)
on page 121
CZ165-60116 Top cover with guide assembly
ADF top cover assembly (M177
model) on page 125
CZ181-60104 Scan drive system assembly
Scanner assemblies (M176
model) on page 115
CZ181-60104 Scan drive system assembly
Scanner assembly (M177 model)
on page 121
CZ181-60107 Core ADF assembly
Document feeder assembly
(M177 model) on page 123
CZ181-60113 Scanner with spring assembly
Scan drive system (M176 and
M177 models) on page 117
CZ185-40001 Fax rubber cap (M177 model) (not shown)
Covers, panels, and doors
on page 109
RC3-0230-000CN Support, frame
Internal assemblies on page 111
RC3-5146-000CN Cover, dust
Covers, panels, and doors
on page 109
RC3-5345-000CN Cover, fuser
Covers, panels, and doors
on page 109
RC3-5348-000CN Cover, right
Covers, panels, and doors
on page 109
RC3-5353-000CN Cover, flat cable
Covers, panels, and doors
on page 109
RC3-5357-000CN Door, cartridge
Covers, panels, and doors
on page 109
RC3-5365-000CN Cover, grounding cable
Internal assemblies on page 111
RL1-2671-000CN Roller, paper pick-up
Internal assemblies on page 111
RL1-3930-000CN Left cover assembly
Covers, panels, and doors
on page 109
RL1-3936-000CN Right upper cover assembly
Covers, panels, and doors
on page 109
RM2-0138-000CN Upper cover assembly
Covers, panels, and doors
on page 109
