Table 2-19 Numerical parts list (continued)
Part number Description Table and page
RM2-0139-000CN Inner cover assembly
Internal assemblies on page 111
RM2-0142-000CN Operation panel assembly
Covers, panels, and doors
on page 109
RM2-0144-000CN Main tray assembly
Internal assemblies on page 111
RM2-0157-000CN Fuser delivery assembly (110-127 V)
Internal assemblies on page 111
RM2-0160-000CN Base plate assembly
Internal assemblies on page 111
RM2-0162-000CN Rear cover/secondary transfer assembly
Covers, panels, and doors
on page 109
RM2-0164-000CN Power supply cover assembly
Covers, panels, and doors
on page 109
RM2-0167-000CN Fuser delivery assembly (220–240 V)
Internal assemblies on page 111
RM2-0168-000CN Extension tray assembly
Covers, panels, and doors
on page 109
RM2-0170-000CN Separation pad assembly
Internal assemblies on page 111
RM2-0175-000CN Intermediate transfer belt assembly (ITB)
Internal assemblies on page 111
RM2-7292-000CN Low voltage power supply assembly (110-127V)
Internal assemblies on page 111
RM2-7293-000CN Low voltage power supply assembly (220-240V)
Internal assemblies on page 111
RM2-7300-000CN Engine controller PCA
Internal assemblies on page 111
ENWW Numerical parts list 133
