3. Release the arm (callout 2) from the top cover (callout 1).
Figure 1-23 Remove the top cover (2 of 5)
2
1
4. Release two tabs (callout 1) on the fuser cover.
Figure 1-24 Remove the top cover (3 of 5)
1
22 Chapter 1 Removal and replacement ENWW
